在debian 12 6.6内核上无法使用aic8800芯片的无法网卡
大家好，
我有一台赛昉科技的visionfive2开发板，操作系统为debian12 for RISCV版本，内核为6.6.20，USB无线网卡为TP-Link TL-XDN7000H，驱动模块为
user@starfive:~/下载/initramfs$ sudo modinfo aic8800_fdrv
filename: /lib/modules/6.6.20-starfive/kernel/drivers/net/wireless/aic8800/aic8800_fdrv/aic8800_fdrv.ko
license: GPL
author: Copyright(c) 2015-2017 RivieraWaves RivieraWaves S.A.S
version: 6.4.3.0
description: RivieraWaves 11nac driver for Linux cfg80211
firmware: rwnx_settings.ini
import_ns: VFS_internal_I_am_really_a_filesystem_and_am_NOT_a_driver
firmware: fmacfw.bin
firmware: fmacfw.ihex
firmware: ldpcram.bin
firmware: fcuram.bin
firmware: agcram.bin
srcversion: 76B7DF7CB1049E2E4B15C35
alias: usb:vA69Cp88DDddcdscdpiciscipin
alias: usb:vA69Cp88DCddcdscdpicFFiscFFipFFin*
alias: usb:vA69Cp8D81ddcdscdpicFFiscFFipFFin*
alias: usb:vA69Cp8801ddcdscdpicFFiscFFipFFin*
depends: aic_load_fw
intree: Y
name: aic8800_fdrv
vermagic: 6.6.20-starfive SMP mod_unload modversions riscvRANDSTRUCT_32719b72561f88f8fca345f99b770f62cb4ac82689928457cdae02c26550bcbb
parm: align_param:int
parm: ant_div:Enable Antenna Diversity (Default: 1) (bool)
parm: ht_on:Enable HT (Default: 1) (bool)
parm: vht_on:Enable VHT (Default: 1) (bool)
parm: he_on:Enable HE (Default: 1) (bool)
parm: mcs_map:VHT MCS map value 0: MCS0_7, 1: MCS0_8, 2: MCS0_9 (Default: 2) (int)
parm: he_mcs_map:HE MCS map value 0: MCS0_7, 1: MCS0_9, 2: MCS0_11 (Default: 2) (int)
parm: he_ul_on:Enable HE OFDMA UL (Default: 0) (bool)
parm: amsdu_maxnb:Maximum number of MSDUs inside an A-MSDU in TX: (Default: NX_TX_PAYLOAD_MAX) (int)
parm: ps_on:Enable PowerSaving (Default: 1-Enabled) (bool)
parm: tx_lft:Tx lifetime (ms) - setting it to 0 disables retries (Default: 1000) (int)
parm: ldpc_on:Enable LDPC (Default: 1) (bool)
parm: stbc_on:Enable STBC in RX (Default: 1) (bool)
parm: gf_rx_on:Enable HT greenfield in reception (Default: 1) (bool)
parm: phycfg:0 <= phycfg <= 5 : RF Channel Conf (Default: 2(C0-A1-B2)) (int)
parm: uapsd_timeout:UAPSD Timer timeout, in ms (Default: 300). If 0, UAPSD is disabled (int)
parm: uapsd_queues:UAPSD Queues, integer value, must be seen as a bitfield
Bit 0 = VO
Bit 1 = VI
Bit 2 = BK
Bit 3 = BE
→ uapsd_queues=7 will enable uapsd for VO, VI and BK queues (int)
parm: ap_uapsd_on:Enable UAPSD in AP mode (Default: 1) (bool)
parm: sgi:Advertise Short Guard Interval support (Default: 1) (bool)
parm: sgi80:Advertise Short Guard Interval support for 80MHz (Default: 1) (bool)
parm: use_2040:Use tweaked 20-40MHz mode (Default: 1) (bool)
parm: use_80:Enable 80MHz (Default: 1) (bool)
parm: custregd:Use permissive custom regulatory rules (for testing ONLY) (Default: 0) (bool)
parm: custchan:Extend channel set to non-standard channels (for testing ONLY) (Default: 0) (bool)
parm: nss:1 <= nss <= 2 : Supported number of Spatial Streams (Default: 1) (int)
parm: amsdu_rx_max:0 <= amsdu_rx_max <= 2 : Maximum A-MSDU size supported in RX
0: 3895 bytes
1: 7991 bytes
2: 11454 bytes
This value might be reduced according to the FW capabilities.
Default: 2 (int)
parm: bfmee:Enable Beamformee Capability (Default: 1-Enabled) (bool)
parm: bfmer:Enable Beamformer Capability (Default: 0-Disabled) (bool)
parm: mesh:Enable Meshing Capability (Default: 1-Enabled) (bool)
parm: murx:Enable MU-MIMO RX Capability (Default: 1-Enabled) (bool)
parm: mutx:Enable MU-MIMO TX Capability (Default: 1-Enabled) (bool)
parm: mutx_on:Enable MU-MIMO transmissions (Default: 1-Enabled) (bool)
parm: roc_dur_max:Maximum Remain on Channel duration (int)
parm: listen_itv:Maximum listen interval (int)
parm: listen_bcmc:Wait for BC/MC traffic following DTIM beacon (bool)
parm: lp_clk_ppm:Low Power Clock accuracy of the local device (int)
parm: tdls:Enable TDLS (Default: 1-Enabled) (bool)
parm: uf:Enable Unsupported HT Frame Logging (Default: 0-Disabled) (bool)
parm: auto_reply:Enable Monitor MacAddr Auto-Reply (Default: 0-Disabled) (bool)
parm: ftl:Firmware trace level (Default: “”) (charp)
parm: dpsm:Enable Dynamic PowerSaving (Default: 1-Enabled) (bool)
parm: country_code:string
parm: ccode_channels:string
parm: aicwf_dbg_level:int
parm: reorder_timeout:int
固件为
sudo modinfo aic_load_fw
filename: /lib/modules/6.6.20-starfive/kernel/drivers/net/wireless/aic8800/aic_load_fw/aic_load_fw.ko
license: GPL
author: Copyright(c) 2015-2020 AICSemi AICSemi
version: 1.0
description: AIC BLUETOOTH
firmware: fw.bin
srcversion: F91445FE2B12AF8F44B99B6
alias: usb:vA69Cp8D81ddcdscdpiciscipin
alias: usb:vA69Cp8D80ddcdscdpiciscipin
alias: usb:vA69Cp8801ddcdscdpiciscipin
alias: usb:vA69Cp8800ddcdscdpiciscipin
depends:
intree: Y
name: aic_load_fw
vermagic: 6.6.20-starfive SMP mod_unload modversions riscvRANDSTRUCT_32719b72561f88f8fca345f99b770f62cb4ac82689928457cdae02c26550bcbb
parm: aic_fw_path:string
parm: aicwf_dbg_level:int
parm: ble_scan_wakeup_reboot_time:int
parm: testmode:int
parm: adap_test:int
parm: paringid:string
dmesg信息为
user@starfive:~/下载/initramfs$ dmesg
[316794.809258] usb 1-1.1: USB disconnect, device number 11
[316794.814816] aicwf_usb_disconnect enter
[316820.460952] usb 1-1.1: new high-speed USB device number 12 using xhci_hcd
[316820.593893] usb-storage 1-1.1:1.0: USB Mass Storage device detected
[316820.600981] scsi host0: usb-storage 1-1.1:1.0
[316821.611768] scsi 0:0:0:0: Direct-Access AIC flash 1.0 PQ: 0 ANSI: 4
[316821.624856] sd 0:0:0:0: [sda] 7904 512-byte logical blocks: (4.05 MB/3.86 MiB)
[316821.633107] sd 0:0:0:0: [sda] Write Protect is on
[316821.638015] sd 0:0:0:0: [sda] Mode Sense: 03 00 80 00
[316821.639433] sd 0:0:0:0: [sda] No Caching mode page found
[316821.644933] sd 0:0:0:0: [sda] Assuming drive cache: write through
[316821.658015] sda: sda1
[316821.664726] sd 0:0:0:0: [sda] Attached SCSI removable disk
[316822.502284] sd 0:0:0:0: [sda] tag#0 UNKNOWN(0x2003) Result: hostbyte=0x07 driverbyte=DRIVER_OK cmd_age=0s
[316822.512046] sd 0:0:0:0: [sda] tag#0 CDB: opcode=0x1b 1b 00 00 00 02 00
[316822.519437] usb 1-1.1: USB disconnect, device number 12
[316823.190813] usb 1-1.1: new high-speed USB device number 13 using xhci_hcd
[316823.325133] AICWFDBG(LOGINFO) aicwf_usb_probe vid:0xA69C pid:0x8D80 icl:0x0 isc:0x0 ipr:0x0
[316823.333851] AICWFDBG(LOGINFO) aicloadfw_chipmatch USE AIC8800D80
[316823.340443] Aic high speed USB device detected
[316823.347790] chip_id=7
[316823.350185] aic_load_firmware :firmware path = /lib/firmware/aic8800/fw_adid_8800d80_u02.bin
[316823.359202] file md5:f546881a81b960d89a672578eb45a809
[316823.364528] ### Upload fw_adid_8800d80_u02.bin firmware, @ = 201940 size=1708
[316823.372359] fw download complete
[316823.377281] aic_load_firmware :firmware path = /lib/firmware/aic8800/fw_patch_8800d80_u02.bin
[316823.386828] file md5:a253bc880de32539b6c29435ed66e895
[316823.392146] ### Upload fw_patch_8800d80_u02.bin firmware, @ = 20b43c size=25300
[316825.450726] cmd timed-out
[316825.453468] tkn[21] flags:0012 result: -4 cmd:1035 - reqcfm(1036)
[316825.459986] cmd queue crashed
[316825.463131] bin upload fail: 21003c, err:-32
[316825.467766] fw download complete
[316825.472781] aicwf_bus_deinit
[316825.973197] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316825.983097] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316825.989928] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316825.998252] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316826.005098] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316826.011863] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316826.018671] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316826.025491] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316826.032343] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316826.039140] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316826.046025] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316826.052896] usb_err:<aicwf_usb_rx_submit_all_urb,230>: bus is not up=0
[316826.059667] usb bustx thread will to stop
[316826.063834] usb bustx thread stop
[316826.067300] exit aicwf_bus_deinit
[316826.070857] usb_err:<aicwf_usb_probe,1633>: failed with errno 0
[327294.155205] starfive-dwmac 16030000.ethernet eth0: Link is Down
[327298.315412] starfive-dwmac 16030000.ethernet eth0: Link is Up - 1Gbps/Full - flow control rx/tx
[327312.874058] starfive-dwmac 16030000.ethernet eth0: Link is Down
[327337.834407] starfive-dwmac 16030000.ethernet eth0: Link is Up - 1Gbps/Full - flow control rx
